Industrial Inkjet Printers

X5 UV Flatbed Printer

X5 UV Flatbed Printer

The X5 UV printer is a high-performance flatbed that can print a full 43.3″ x 24″ (1,100 x 610 mm) area in two minutes (uni- or bi-directional). Utilizing the latest in print head technology, the high-throughput X5 prints CMYK plus two highly opaque UV LED-curable white inks, with an optional varnish for additional visual impact.

The X5 is designed for heavy-duty industrial printing and promotional products and features a rugged design that can handle near-constant use. Leveraging a large vacuum table and up to four Ricoh Gen 5 print heads, the X5 is able to print flats and hard goods up to 6″ in height. Ideal for full-color on-demand printing, the X5 enables users to lower production costs, provide faster response to customers, and handle short-run quantities with customization.

Choose from a variety of inks to print with the X5®. The DL Series was formulated for excellent adhesion to glass and plastic. Paired with MagiCoat pre-treatment solution, glassware items can handle up to 200 residential washes (depending on temperature and detergent). The Prop. 65 compliant S1 Series is the perfect solution for a variety of rigid substrates such as stainless steel and metal. Finally, the XFlexx Series is compatible with flexible applications. In addition to the numerous inkjet inks we carry, we also perform all adhesion requirements for you. This is done during the sampling process. Once we have completed adhesion testing according to ASTM, we will send your samples back to you along with the report.

As with all Inkcups flatbed UV printers, the X5® is capable of handling a traveling fixture. Inkcups provides a custom tooling service from concept to build.

All digital machines are backed by InkcupCare Warranty with an extended warranty available as well.

Need help with the X5® or any other digital printer? Visit our FAQs section.

  • 1,100 x 610 mm (43 x 24 in) print area
  • 1200dpi resolution

FEATURES

Applications

Resources

X5 Brochure

Specifications

Product Type
Flat or slightly curved
Bed Size
1100 x 610 mm (43.3 x 24 in)
Speed (based on bed size)
19 m²/hr
Max. Part Height
150 mm (5.9 in)
Lamp Style
2 UV LED
Ink Type
UV LED
Ink Configuration
CMYKWW or CMYKW+Varnish
Print Modes
Uni/Bi
Bulk Ink System
3 Liter
Dimensions (lxwxh)
2540 x 1320.80 x 1403.35 mm (100 x 52 x 55.25 in)
Voltage
220 VAC, Single Phase, 15 AMP
Maximum Resolution
1200dpi
Bed Type
Flatbed
